| MODEL | Configuration | Input MBtuH | Output MBtuH | AFUE | CFM | Dimensions HxWxD | Weight Lbs. |
|---|---|---|---|---|---|---|---|
| R801PA050314M | Upflow / Hor. | 50.0 | 40.0 | 80.0 | 1250 | 34x14x29.5 | 85 |
| R801PA075417M | Upflow / Hor. | 75.0 | 60.0 | 80.0 | 1200 | 34x17.5x29.5 | 105 |
| R801PA100521M | Upflow / Hor. | 100.0 | 80.0 | 80.0 | 1800 | 34x21x29.5 | 115 |
| R801PA125524M | Upflow / Hor. | 125.0 | 100.0 | 80.0 | 1750 | 34x24.5x29.5 | 140 |
| R801PA150524M | Upflow / Hor. | 150.0 | 120.0 | 80.0 | 1900 | 34x24.5x29.5 | 150 |
| R801PA050314Z | Downflow | 50.0 | 41.0 | 80.0 | 1200 | 34x14x29.5 | 85 |
| R801PA075317Z | Downflow | 75.0 | 60.0 | 80.0 | 1200 | 34x17.5x29.5 | 105 |
| R801PA075417Z | Downflow | 75.0 | 60.5 | 80.0 | 1600 | 34x17.5x29.5 | 105 |
| R801PA100317Z | Downflow | 100.0 | 80.0 | 80.0 | 1200 | 34x17.5x29.5 | 115 |
| R801PA100521Z | Downflow | 100.0 | 81.0 | 80.0 | 2000 | 34x21x29.5 | 120 |
| R801PA125524Z | Downflow | 125.0 | 99.0 | 80.0 | 2000 | 34x24.5x29.5 | 140 |
| R801PA150524Z | Downflow | 150.0 | 120.0 | 80.0 | 2000 | 34x24.5x29.5 | 150 |
